MBS Type Rod Mill-Zhongde Heavy Industries

PRODUCTION INTRODUCTION

This rod mill can be used as an open-circuit grinding mill, which is widely used in mineral processing, building materials, chemicals, refractory materials and other industries as well as the grinding operations which has higher requirements of finished products uniformity. It is also widely used in the construction sand production industry in recent years. At present, it is a relatively more advanced, high-efficiency and energy-saving gravel sand equipment in the world, its performance has reached the international leading level.

1500–3600mmDiameter

THE MAIN BENEFITS AND ADVANTAGES

Unique structure

1. Good energy saving effect MBS type rod mill energy-saving effect is higher than traditional grinding machine about 50% when it works.

2. Wide application range MBS type rod mill can be used in refractory materials, chemical industry, metallurgy, highways, railways and glass industry as well as on the grinding operation which has higher requirement of finished products uniformity, it can also be used in construction sand production industry.

Easy operation

The rod Mill has dry and wet two forms to choose from, users can choose according to own actual situation. The rod mill is named after its grinding media-steel rod. MBS type rod mill researched and developed by ZDZG adopts advanced production technology, combined with the actual production of grinding materials, and coupled with high-quality grinding body, change the traditional surface contact to line contact, so that get a more uniform product particle and higher yield.

Technical Parameter

to view more

Model	Shell Specifications （mm）		Shell rotation speed （r/min）	Feeding size (mm)	Discharging size (mm)	Processing capacity (t/h)	Power (kw)	Total weight (t)
Model	Diameter	Length	Shell rotation speed （r/min）	Feeding size (mm)	Discharging size (mm)	Processing capacity (t/h)	Power (kw)	Total weight (t)
MBS0918	900	1800	36-38	≤25	0.833-0.147	0.62-3.2	18.5	5.9
MBS0924	900	2400	36	≤25	0.833-0.147	0.81-4.3	22	6.7
MBS1224	1200	2400	36	≤25	0.833-0.147	1.1-4.9	30	13.9
MBS1530	1500	3000	29.7	≤25	0.833-0.147	2.4-7.5	75	19.8
MBS1830	1830	3000	25.4	≤25	0.833-0.147	4.8-11.6	130	34.9
MBS2130	2100	3000	23.7	≤25	0.833-0.147	14-35	155	46.5
MBS2136	2100	3600	23.7	≤25	0.833-0.147	19-43	180	48.7
MBS2430	2400	3000	21	≤50	0.833-0.147	25-65	245	59.7
MBS2736	2700	3600	20.7	≤50	0.833-0.147	32-86	380	92.5
MBS2740	2700	4000	20.7	≤50	0.833-0.147	32-92	400	95
MBS3245	3200	4500	18	≤50	0.833-0.147	64-180	630	149

Model	Feeding size (mm)	Processing capacity (t/h)
MBS0918	≤25	0.62-3.2
MBS0924	≤25	0.81-4.3
MBS1224	≤25	1.1-4.9
MBS1530	≤25	2.4-7.5
MBS1830	≤25	4.8-11.6
MBS2130	≤25	14-35
MBS2136	≤25	19-43
MBS2430	≤50	25-65
MBS2736	≤50	32-86
MBS2740	≤50	32-92
MBS3245	≤50	64-180
